Locking Proximal Femur Plate 5.0/7.0mm
- Raw Material: Stainless Steel & Titanium
This Plate Is To Be Use In
Indications :
- Fractures of the Trochentric Region, Trochantric Simple, Cervicotrochantric, Trochanterrodiaphyseal, Miltifragmentary Pertrochantric, Intertrochentric Reversed Or Transverse Fracture.
- Fractures Of The Proximal End Of The Femur Combined With Ipsilateral Shaft Fractures.
- Metastic Fracture Of The Proximal Femur.
- Osteotomies Of The Proximal Femur.
- Use In Fixation Of Osteopenic Bone & Fixation Of Nonunion Or Malunion.
Description
Following Screws are to be use with above Plates:
A) 5.0mm Locking Head Screw – Self Tapping
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
106.314 To 106.390 | 14mm To 90mm | Ti.106.314 To Ti.106.390 |
Stainless Steel | Star Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
106.414 To 106.490 | 14mm To 90mm | Ti.106.414 To Ti.106.490 |
B) 7.0mm Locking Cannulated Cancellous Screw 16mm Thread
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
111.150 To 111.210 | 50mm To 110mm | Ti.111.150 To Ti.111.210 |
C) 7.0mm Locking Cannulated Cancellous Screw 32mm Thread
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
112.160 To 112.210 | 50mm To 110mm | Ti.112.150 To Ti.112.210 |
Following Instruments to be use with above Plate:
Cat No. | Description |
---|---|
260.430 | Drill Bit – S.S. – Quick Coupling End Dia. 4.3mm X 221mm Long – Calibrated |
301.029 | Hexagonal Screw Driver with Self Holding Sleeve 3.5mm Tip (for 5.0mmLocking Head & 5.0mm Locking Cancellous Screw) |
301.050 | Large Hexagonal Screw Driver 3.5mm Tip – Silicon Handle |
303.020 | Large Depth Gauge |
803.110 | LCP Drill Sleeve 5.0mm for Drill Bit 4.3mm |
803.112 | Tap for 5.0mm Locking Head Screws |
804.164 | Q.C. Torque Screw Driver Handle 3.5mm Tip (Torque 4.0Nm) |
804.170 | Hexagonal Screw Driver Q.C. End Shaft, 3.5mm Tip(For Torque Handle 4.0N.M) |
XP.301.082 | Star Drive Screw Driver – 3.5mm Tip/T-20 |
703.010 | Cannulated Drill Bit 4.5mm |
703.011 | Cannulated Tap with T – Handle 7.0mm |
703.015 | Threaded Guide Wire Dia 2.0mm. X Length 230mm |
703.016 | Large Cannulated Hexagonal Screw Driver 3.5mm Tip – Sillicon Handle |
803.111 | LCP Drill Sleeve 7.0mm for Drill Bit 4.5mm (Use With Proximal Femur Plate) |
Following Size of Locking Proximal Femur Plate 5.0/7.0mm are available in Stainless Steel & Titanium Material.
Cat No. (Stainless Steel) | Holes (Left) | Cat No. (Titanium) |
---|---|---|
870.103 | 3 Holes | Ti.870.103 |
870.105 | 5 Holes | Ti.870.105 |
870.107 | 7 Holes | Ti.870.107 |
870.109 | 9 Holes | Ti.870.109 |
870.111 | 11 Holes | Ti.870.111 |
Cat No. (Stainless Steel) | Holes (Right) | Cat No. (Titanium) |
---|---|---|
870.133 | 3 Holes | Ti.870.133 |
870.135 | 5 Holes | Ti.870.135 |
870.137 | 7 Holes | Ti.870.137 |
870.139 | 9 Holes | Ti.870.139 |
870.140 | 11 Holes | Ti.870.140 |
