Locking Olecranon Plate 3.5/4.0mm Without Extension
-
The 3.5mm Locking Olecranon Plates are Indicated for Fixation of Fractures, Osteotomies and Nonunions of the Olecranon, Particularly in Osteopenic Bone.
Indications:
-
Fractures of Olecranon.
-
Nonunion of Olecranon.
-
Osteotomies of Olecranon.
Following Screws are to be use with Above Plates:
A) 3.5mm Locking Head Screw – Self Tapping
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
102.310 to 102.380 | 10mm to 80mm | Ti.102.310 to Ti.102.380 |
Stainless Steel | Star Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
102.410 to 102.480 | 10mm to 80mm | Ti.102.410 to Ti.102.480 |
B) 4.0mm Locking Head Cancellous Screw Full Thread – Self Tapping
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
105.512 to 105.580 | 12mm to 80mm | Ti.105.512 to Ti.105.580 |
Stainless Steel | Star Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
105.612 to 105.680 | 12mm to 80mm | Ti.105.612 to Ti.105.680 |
C) Cortical Screw 3.5mm Dia. – Self Tapping
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
102.210 to 102.296 | 10mm to 100mm | Ti.102.210 to Ti.102.300 |
D) Cancellous Screw 4.0mm Dia. Short Thread
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
104.010 to 104.085 | 10mm to 85mm | Ti.104.010 to Ti.104.085 |
E) Cancellous Screw 4.0mm Dia. Full Thread
Stainless Steel | Hex Drive | Titanium |
---|---|---|
Cat No. | Size | Cat No. |
105.010 to 105.085 | 10mm to 85mm | Ti.105.010 to Ti.105.085 |
Following Instruments to be use with above Plate:
Cat No. | Description |
---|---|
260.281 | Drill Bit – S.S. Quick Coupling End Dia. 2.8mm X 180mm Long Calibrated |
804.110 | LCP Drill Sleeve 3.5mm for Drill Bit 2.8mm |
804.121 | Tap for 3.5mm Locking Head Screws |
804.163 | Q.C. Torque Screw Driver Handle 2.5mm Tip (Torque 1.5Nm) |
804.168 | Hexagonal Screw Driver Q.C. End Shaft, 2.5mm Tip (for Torque Handle 1.5Nm) |
260.250 | Drill Bit – S.S. Quick Coupling End Dia. 2.5mm x 115mm Long |
264.025 | Bone Tap – Quick Coupling End Dia. 3.5mm, Thread Length50mm, Total Length 110mm |
260.270 | Drill Bit – S.S. – Quick Coupling Dia. 2.7mm X 125mm Long |
264.037 | Bone Tap Quick Coupling End Dia. 4.0mm – Cancellous, Thread Length 85mm, Total Length 110mm |
301.040 | Small Hexagonal Screw Driver 2.5mm Tip – Silicon Handle |
301.026 | Hexagonal Screw Driver With Self Holding Sleeve 2.5mm Tip (for 2.7mm Cortical, 3.5mm & 4.0mm Locking Head screws) |
301.025 | Hexagonal Screw Driver with Self Holding Sleeve 2.5mm Tip (for 3.5mm Cortical & 4.0mm Cancellous Screws) |
303.010 | Small Depth Gauge |
XP.301.081 | Star Drive Screw Driver – 2.5mm Tip/T-15 |
Following Size of Locking Olecranon Plate 3.5/4.0mm Without Extension are available in Stainless Steel & Titanium Material.
Cat No. (Stainless Steel) | Holes (Left) | Cat No. (Titanium) |
---|---|---|
865.223 | 3 Holes | Ti.865.223 |
865.225 | 5 Holes | Ti.865.225 |
865.227 | 7 Holes | Ti.865.227 |
865.229 | 9 Holes | Ti.865.229 |
Cat No. (Stainless Steel) | Holes (Right) | Cat No. (Titanium) |
865.203 | 3 Holes | Ti.865.203 |
865.205 | 5 Holes | Ti.865.205 |
865.207 | 7 Holes | Ti.865.207 |
865.209 | 9 Holes | Ti.865.209 |
